Trak Racer TR160 V5 MK5 Racing Simulator

The TR160 V5 uses the TR One Wheel Mounting System, which is compatible with all major direct-drive and belt-drive wheelbases — including Simagic Alpha and EVO, Fanatec, Moza, Asetek, Simucube, Logitech, Thrustmaster, Cammus, VRS and more. The recommended wheelbase torque range is 0 to 30Nm and beyond. The wheel uprights are side-mounted with heavy-duty brackets and strengthened 160×40mm corner brackets for a no-flex experience even with the strongest direct-drive force feedback.

The TR160 V5 offers three pedal mounting options — a pre-drilled fine-tune slide plate, an extruded profile with heel plate, and a strengthened Hybrid Pedal Plate. All three are pre-drilled for all major pedal brands, including Heusinkveld, Simagic, Fanatec, Asetek, Moza, Logitech and Thrustmaster, and withstand hundreds of kilograms of braking force without flex. The included TR One Gen 2 Expandable Shifter Mount, plus new side-mounts for handbrakes and flight-sim peripherals, attach directly to the plate or to any 8mm aluminium profile.

No — the TR160 V5 includes the Premium Dual-Lock seat slider rails, but a seat is not included. This lets you choose the seat that best suits your driving style. Trak Racer offers GT-style and Rally-style fixed fibreglass seats and a reclining sport seat, all of which mount to the included slider rails. See the "Complete your sim cockpit" section below to add a seat.

The TR160 V5 includes the TR One Wheel Mount; your selected pedal mount (Pre-Drilled Plate, Extrusion with Heel Plate, or Hybrid Pedal System); the Universal Gen 2 Shifter Mount with oversized shifter support; Premium Dual-Lock Seat Slider Rails; bonus rubber feet to protect floors; a set of cable ties and clips; coloured dust strips; all mounting screws, brackets and fixtures; and an assembly tool kit. A seat, monitor stand and motion system are sold separately.

Yes — the TR160 V5 is motion-ready as a direct fit, with no base required. Rather than just moving your seat, you can get the whole frame moving with a full-frame motion system. Contact us and we'll help you spec a motion system that suits the TR160 V5.

Monitor stands are available as optional accessories. The cockpit-mounted single monitor stand supports displays up to 80", and the cockpit-mounted triple monitor stand supports displays up to 45" (including quad configurations). Both bolt directly to the TR160 V5 frame for a stable, integrated viewing setup. See the "Complete your sim cockpit" section below.

Absolutely. The TR160 V5 is built around a huge accessory ecosystem with 30+ optional accessories — seats, single and triple monitor stands, universal caster wheels with brake, bass shaker / tactile transducer mounts, sim floors and more. New side-mounts for handbrakes and flight-sim peripherals attach directly to the plate or to any 8mm aluminium profile, so the rig grows with you.

Assembly takes approximately 7 or more hours. The TR160 V5 ships with all mounting screws, brackets and fixtures plus an assembly tool kit, and is designed and engineered in Australia. It is a serious, heavily adjustable frame, so we recommend setting aside time and following the assembly guide carefully. If you get stuck, our team is happy to help.

The TR160 V5 has a frame footprint of 580mm wide by 1,400mm long, and an assembled size of 660mm by 1,445mm. It weighs 41kg (90.4 lbs) of rigid frame and has low ground clearance, with hardwood rubber floor protectors included to protect your floors.

Yes — with the strengthened Hybrid Pedal Plate, the pedal mount is 4-way adjustable and quick-adjusts between GT (low), Formula (high) and inverted positions. Combined with the slide-and-angle-adjustable TR One Wheel Mount and the Dual-Lock seat slider rails, you can dial in a GT or Formula driving position to suit your car and discipline.

The TR One Wheel Mounting System is the new benchmark in sim-racing wheel mounting. It is future-proof: when you upgrade your wheelbase, you only replace the part of the mount needed for the new base, rather than buying a whole new mount. The base kit includes two 80×40mm aluminium profiles and four anodized aluminium plates and is fully adjustable for both slide and angle.

Player1 Sim Gear is an Australian Trak Racer retailer, and your purchase is covered by Australian Consumer Law, which provides statutory guarantee rights such as repair, replacement or refund for major failures. Our team are active sim racers and can help with pre-sale advice, compatibility checks, assembly guidance and accessory selection. For any support question, use the "Send us a message" button below to reach us directly, or call us on 0488 385 870.

Player1 Sim Gear ships the TR160 V5 Australia-wide. As a large, heavy cockpit frame it is dispatched on a freight service to your address. Delivery timeframes vary by location across Australia. For current stock availability and a delivery estimate to your suburb, call us on 0488 385 870 or send us a message and we'll confirm before you order.

Trak Racer has been building racing cockpits since 2008 and is the official and trusted simulator supplier to the Alpine F1 Team and Airbus Aircraft. Their rigs are used by Alpine F1 and Alpine Academy drivers including Esteban Ocon, Victor Martins and Caio Collet, and are trusted by professional drivers, game centres, major gaming events and event-hire companies. Collaborations include Alpine F1, Airbus, Xbox, Ubisoft, Sony and Castrol.
